2027 Yamaha Grizzly 110 Tactical Green/Acid Green

  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green
  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green
  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green
  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green
  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green
  • 2027 Yamaha Grizzly 110 Tactical Green/Acid Green

CURRENT PROMOTIONS

Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

LITTLE BEAR, BIG PERFORMANCE. A potent 112cc engine and proven off-road performance wrapped in Grizzly styling makes the Grizzly 110 perfect for new trail riders age 10 and up.

Specifications
Model
Grizzly
Category Name
ATVs
Year
2027
Sale Type
New
Manufacturer
Yamaha
Color
Tactical Green/Acid Green
engine
ENGINE
Air-cooled, SOHC 4-stroke; 2 valves
Ignition
CDI
Starting
Electric & Kickstart
FINAL DRIVE
O-ring Chain Drive
DISPLACEMENT
112cc
TRANSMISSION
CVT; F, N, R
FUEL DELIVERY
Yamaha Fuel Injection (YFI), 22mm
BORE AND STROKE
52.4mm x 51.8mm
COMPRESSION RATIO
9.2:1
chassis
TIRES (REAR)
AT18 x 9-8
BRAKES (REAR)
Drum
TIRES (FRONT)
AT19 x 7-8
BRAKES (FRONT)
Dual Drum
SUSPENSION (REAR)
Monoshock swingarm; 5.7" travel
SUSPENSION (FRONT)
Single A-arm, 5" travel
highlights

2027 Yamaha Grizzly 110 Tactical Green/Acid GreenFuel-Injected 112cc Powerplant

The Grizzly 110 is engineered to maximize fun for young ATV riders ages 10 and up. A potent 112cc fuel-injected engine tuned for excellent low- to mid-range performance makes the Grizzly 110 the ideal platform for building skill and confidence from the very first ride.

2027 Yamaha Grizzly 110 Tactical Green/Acid GreenReduced Maintenance Design

Proven, durable components keep servicing simple and affordable, including a toolless quick-access air filter element for hassle-free maintenance.

2027 Yamaha Grizzly 110 Tactical Green/Acid GreenScaled Down, Not Scaled Back

The Grizzly 110 takes cues from the full-size Grizzly with a fully automatic CVT transmission featuring reverse, a gated shifter, and electric start. The result is accessible, confidence-inspiring performance with genuine Grizzly family character.

2027 Yamaha Grizzly 110 Tactical Green/Acid GreenAdventure-Ready Chassis

Compact A-arm front suspension is tuned for light steering and a comfortable ride quality with 5 inches of travel, while the rear swingarm delivers 5.7 inches of wheel travel to give the Grizzly 110 a full-size look and feel for growing riders.

2027 Yamaha Grizzly 110 Tactical Green/Acid GreenRenowned Grizzly Traction

Following in the footsteps of the Proven Off-Road big-bore bear, the Grizzly 110 runs aggressive tires for maximum traction on any trail. Oversized 19-inch front tires and complementing 18-inch rears give the compact machine a purposeful, planted stance.



key features
  • Fuel-injected 112cc four-stroke engine
  • Push-Button Electric Start
  • Automatic CVT Transmission
  • Adjustable Throttle Limiter
  • Standard Reverse Gear



critical data
WIDTH
1031.24mm (40.6")
HEIGHT
1005.84 (39.6")
LENGTH
1,562.1mm (61.5")
WHEELBASE
1031.24 (40.6")
WET WEIGHT
142.882 kg. (315 lb.)
SEAT HEIGHT
728.98mm (28.7")
FUEL CAPACITY
6.4 L (1.7 gal)
MINIMUM GROUND CLEARANCE
104.14mm (4.1")
features & benefits

ENGINE

  • Robust 110cc Engine
    • The Grizzly 110's four-stroke SOHC 110cc engine is tuned to develop excellent low- to mid-range performance. The engine utilizes proven wet-sump lubrication and is air-cooled for simplicity, performance and long service life.
  • Push-button electric starting backed up by an auxiliary kick starter.
    • Electric starting makes learning to ride more fun
  • Automatic Transmission
    • Fully automatic, continuously variable transmission (CVT) means no shifting.
    • Handy and something younger riders will appreciate.
    • Standard reverse simplifies maneuvering the Grizzly 110 in tight spots
  • Compact and Durable Drivetrain
    • Engine power is transferred to the rear wheels via a tried-and-true O-ring chain
    • Optimized angle for superior rear shock performance
  • Modern, Reliable Electronics
    • The CDI system means reliable ignition performance, and a sealed maintenance free battery provides worry-free operation. Handlebar-mounted reserve and neutral indicators keep the rider informed in all situations.
  • Spark arrestor equipped exhaust system.
    • Quiet design
    • "Cleanable" spark arrestor prevents stray sparks from exiting the exhaust
    • Heat shield protects young riders from hot components

Chassis

  • Adventure-Ready Chassis
    • Compact A-arm front suspension is tuned for light steering and comfortable ride quality offering 5" of travel.
    • Swingarm setup in the rear brings with it 5.7" of wheel travel, adding to the Grizzly 110's full-size look and feel.
  • Integrated Cargo Racks
    • Robust steel cargo racks front and rear both boast 11 lb. carrying capacity
    • Provide younger riders the ability to pack their own gear as they join the family on their next adventure
  • Renowned Grizzly Traction
    • Equipped with rugged, trail rated tires, the Grizzly 110 is ready to go anywhere
    • 19" up front and 18" in the rear.
    • Maximize traction on a wide variety of terrain.
  • Big, Mud-Deflecting Fenders
    • The Grizzly 110 boasts full-coverage fenders just like its Grizzly sibling.
    • Enhances styling and protection for the ride from mud and trail debris.
  • Comfortable Accommodations
    • The Grizzly 110 is designed to be comfortable for a wide variety of riders aged 10 years or older
    • With its large and plush seat matched to wide floorboards, riders will enjoy years of riding as they hone their off-road riding skills

SAFETY FEATURES

  • Keyed ignition lets parents control use
  • Heat shields on exhaust protect young riders from hot components
  • Adjustable speed limiter screw on throttle housing restricts throttle lever movement to reduce acceleration & top speed.
  • 2-stage rpm limiter device limits engine rpm. As skills improve, the limiter can be removed & maximum engine rpm will increase from 4,900 rpm to 8,500 rpm making a significant difference in power & performance.
